With an ever heavier box-style,welded spine contributes added stiffness to these steel saw frames to withstand high tension from 35mm resaw blades.The strength of the bandsaw body allows the blade to be tensioned to 20000psi for accurate cutting.
Running at 1500m/min,the BS600 providing a cleaner,faster cut with a better finish.All design are service for lasting performance and it's the ideal bandsaw for industrial use in workshop.
Solid cast iron bandwheel and reliable dual support tension system.
Heavier box-style,welded spine contributes high strength to accurate cutting.
Bearing blade guides simplify adjustments.
Oversize casting trunnions that lend solid foundation below and driven by gear for easy tilting.
Voltage/Frequency | 400V/50Hz |
Motor output power | 5.5HP |
Blade Length | 4470mm |
Blade Width | 10-35mm |
Blade speed | 1500m/min |
Max Depth of Cut | 370mm |
Max Width of Cut | 580mm |
Table Size | 700×608mm |
Table Tilt | 0-20° |
Bandwheel Dia. | 610mm |
Clean Dia. | 100mm |
Package Size ·Carton box | 1119×777×2190mm |
Net/Gross Weight | 328/385kgs |
Container Load Q'ty ·Carton box load | 14pcs/20' |
