he BS350B is for the busy workshop where power and generous capacity are required but budget and space do not allow a bigger machine.The bandwheels are cast iron and dynamically balanced with precision ground,crowned rubber tyres usually only found on much more expensive industrial machines -the flywheel effect of the cast iron wheels improves cutting performance and speeds.
The rip fence is the strongest and most industrial in its category with a chromed fence and the mount machined from a single piece of cast iron.The extrusion itself is a heavy section to provide rigidity and accuracy.
Industrial Style Fence This high quality fence features a heavy extrusion mounted on a cast iron base,which moves along a solid steel bar.
Large Cast Iron Table Provides a strong and steady work area to support large workpieces.
Cast Iron Band Wheels Are fitted with precision ground rubber tyres to provide a flywheel effect for smooth cutting.
Trunnion Solid double trunnion table mount for rigid table support featuring one handed rack and pinion table tilt for ease of use and accuracy.
Voltage/Frequency | 230V/50Hz 120V/60Hz |
Motor output power | 1.5HP |
Blade Length | 2630mm |
Blade Width | 6-19mm |
Blade speed | 410-860m/min |
Max Depth of Cut | 235mm |
Max Width of Cut | 345mm |
Table Size | 546×400mm |
Table Tilt | 0-45° |
Bandwheel Dia. | 350mm |
Clean Dia. | 100mm |
Package Size ·Carton box | 1295×455×575mm |
Net/Gross Weight | 96/102kgs |
Container Load Q'ty ·Carton box load | 80pcs/20' |
